Directional Antenna 2.4G Panel External

Name: Directional Antenna 2.4G Panel External
Brand: KEESUN
Rating: 5.0 (86 reviews)

Electrical specifications：
FreqRange 2400-2500MHz
Gain 14±1dBi
Horizontal Beamwidth 35±5°
Vertical Beamwidth 35±5°
F/B ＞23dB
VSMR ≤1.8
Impedance 50Ω
Polarization Vertical polarization（V）
Max. Power 50W
Connector N-K
Lightning Protection DC Ground
Mechanical indicators： Mechanical Specifications
mm(Dimension) 190*190*25mm
kg（Weight） 0.5kg
Rated Wind Velocity 36.9 m/s
Operational Humidity < 95％
Operating temperature -40～55℃
Radome material ABS

Model:
KS50043
Brand:
KEESUN
Code:
KS50043

Quantity:
Color:	White
Availability:





Inquire Add to Basket

Product Description

Electrical Specifications
Model	/
FreqRange	2400~2500MHz
Gain	10±1dBi
Horizontal Beamwidth	30±10°
Vertical Beamwidth	90±10°
VSWR	≤1.5
front-to-back ratio（）	≧23dB
Impedance	50Ω
Polarization	±45°
Max. Power	50W
Connector	N-Female
Lightning Protection	DO~Ground
Mechanical Specifications
mm(Dimension)	210mm
kg（Weight）	0.55kg
Rated Wind Velocity	36.9m/s
Operational Humidity	<95％
Operating temperature	-40～55℃
Radome material	ABS（White)

Name1

Name2

Name1

Name2

Our factory is in Shenzhen——Panel antenna

Export advantage of antenna factory lies in strong technical strength, large production scale, reliable quality, strong price competitiveness, and a perfect supply chain and logistics system, which can meet the needs of global customers and is favored by the international market.
