In an era where Unmanned Aerial Vehicles (UAVs) are becoming increasingly accessible, the threat of unauthorized drone incursions has escalated from a simple nuisance to a critical security breach. Our Integrated UAV Detection and Drone Jammer System provides a comprehensive, 24/7 autonomous shield for your airspace, merging long-range passive detection with precision neutralization.
Designed for high-stakes environments, this all-in-one C-UAS (Counter-Unmanned Aircraft System) solution ensures that potential threats are identified, tracked, and mitigated before they can cause harm.
Key Features of Our Integrated Anti-Drone Solution
Our system is engineered to bridge the gap between "seeing" a threat and "stopping" it. By integrating RF sensing, radar, and multi-band jamming into a single platform, we eliminate the latency found in multi-device setups.
1. Advanced Full-Spectrum Detection
Utilizing passive Radio Frequency (RF) scanning and active radar, the system monitors the 100MHz to 6GHz frequency range. It can detect consumer-grade drones (DJI, Autel), DIY FPV drones, and even military-grade UAVs with a detection range of up to 5-10 km.
2. Precision Intelligent Neutralization
Once a threat is confirmed, the integrated jammer activates either automatically or via manual override. It disrupts multiple links simultaneously:
Command & Control: Cuts the pilot’s ability to maneuver the drone.
Video Transmission: Blinds the operator's real-time feed.
GNSS/GPS: Forces the drone to land safely or return to its launch point by disrupting satellite navigation (GPS, GLONASS, BeiDou, Galileo).
3. Smart "White-List" Management
Avoid disrupting your own operations. Our system features an intelligent library that allows for "Friend or Foe" identification, ensuring authorized drones can operate while unauthorized ones are intercepted.
4. Ruggedized for All-Weather Performance
Encased in an IP66 or IP67-rated weather-resistant housing, the system is built to withstand extreme temperatures (-40°C to +70°C), heavy rain, and high winds, making it ideal for coastal or desert installations.
Primary Use Cases: Where Airspace Security Matters Most
Unregulated drone flight can lead to corporate espionage, physical attacks, or operational shutdowns. Our integrated system is deployed globally across diverse sectors:
Critical Infrastructure Protection
Oil refineries, power plants, and water treatment facilities are vulnerable to drone-borne payloads. Our system creates a "no-fly zone" perimeter, ensuring continuous protection against sabotage or surveillance.
Airport & Maritime Port Security
A single drone near a runway can ground hundreds of flights. Our system provides long-range early warning to airport security, allowing them to neutralize the drone without interfering with legitimate aircraft communications.
Prison & Correctional Facility Security
Drones are frequently used to smuggle contraband (phones, drugs, weapons) over prison walls. The UAV Detection & Jammer System detects the unique RF signatures of smuggling drones and triggers an immediate jamming response to drop the payload outside the secure zone.
Public Event & Stadium Safety
From VIP protection to large-scale sports events, unauthorized drones pose a crowd safety risk. Our portable and stationary versions ensure that "camera drones" or hostile UAVs are safely managed away from the public.
Technical Specifications
| Feature | Specification |
| Detection Method | Passive RF Sensing + Active Phased Array Radar |
| Detection Range | 3km to 10km (Customizable) |
| Jamming Range | 1.5km to 5km (Line of Sight) |
| Frequency Coverage | 433MHz, 900MHz, 1.2GHz, 1.4GHz, 2.4GHz, 5.8GHz |
| Response Time | ≤3 seconds from detection to neutralization |
| Tracking Capacity | Up to 30+ targets simultaneously |
| Control Interface | Ethernet/Web-based GUI with Google Maps Integration |
| Operational Modes | Fully Automatic, Semi-Auto, and Manual |
Why Choose Our Integrated C-UAS Solution?
Unlike standalone jammers that require a human operator to "spot" a drone visually, our integrated system operates autonomously. This reduces the margin of human error and ensures protection in low-visibility conditions like night, fog, or heavy rain.
Moreover, as an antenna and RF specialist factory, we provide customized frequency tuning to meet the specific legal and signal requirements of your region. Whether you need a vehicle-mounted mobile unit for convoys or a fixed-site installation for a government building, our engineering team provides end-to-end support.
