The landscape of modern wireless technology demands precision, reliability, and adaptability. Our N Male to SMA Male RG316 RF Coaxial Cable Assembly is engineered to meet these rigorous standards, providing a professional-grade, high-performance solution for a wide array of radio frequency (RF) applications. This custom cable is the critical link required to seamlessly connect devices with robust Type N interfaces to equipment utilizing the popular subminiature SMA interface, all while ensuring minimal signal degradation across high-frequency bands.
Crafted with the gold standard in flexible, high-temperature coaxial cable—RG316—this assembly is designed for scenarios where space is limited, repeated flexing is necessary, and high-frequency stability is paramount. The combination of its durable, versatile cable type and precision-machined connectors makes it an indispensable tool for engineers, telecommunications professionals, and dedicated hobbyists alike. Whether you are setting up a professional wireless network, conducting sophisticated lab measurements, or deploying IoT and LoRa devices, this cable delivers the clear,
Key Features and Technical Excellence
The superior performance of our N Male to SMA Male RG316 cable assembly stems from its deliberate design and material selection. Understanding these core features is key to appreciating its value in critical RF systems.
The RG316 Advantage: Flexibility Meets Performance
The RG316 coaxial cable is the foundational element of this assembly. Unlike thicker, less flexible alternatives, RG316 offers a unique balance:
High Flexibility: Its compact, small diameter and stranded inner conductor (often silver-plated copper-clad steel) allow for extremely tight bends and easy routing in crowded enclosures or compact installations without compromising electrical integrity.
Low Attenuation at High Frequencies: Despite its small size, RG316 performs excellently across a broad frequency spectrum, typically up to 3 GHz and often beyond. Its PTFE (Polytetrafluoroethylene) dielectric provides superior thermal stability and low loss characteristics, ensuring your signal remains strong over short to moderate runs.
Robust Construction: The outer jacket, often FEP or PTFE, provides exceptional resistance to abrasion, chemicals, and extreme temperatures, making it suitable for demanding indoor and certain outdoor environments.
50 Ohm Impedance: The standard impedance for most RF, wireless, and data communication systems, ensuring optimal power transfer and minimal reflections when paired with matched equipment.
Precision Connector Interface: N Male to SMA Male
The connectors define the compatibility and reliability of the cable:
N Male Connector (Type-N): A medium-sized, threaded, and robust connector known for excellent mechanical stability and high-power handling. The N Male connector is typically used for connecting to outdoor antennas, base stations, or high-power lab equipment where a secure, weatherproof connection (when properly torqued) is essential. The screw-on coupling mechanism ensures a vibration-proof seal.
SMA Male Connector (Sub-Miniature A): A smaller, semi-precision threaded connector widely used in countless modern RF devices due to its compact size and reliable high-frequency performance (often rated up to 18 GHz). The SMA Male end connects to the internal threads of an SMA Female Jack, commonly found on wireless routers, modems, test probes, and small embedded systems.
The seamless transition between these two critical connector types is what makes this cable a versatile asset in RF system integration.
Diverse Application Scenarios (Use Cases)
The unique attributes of the N Male to SMA Male RG316 cable assembly make it essential for solving numerous interconnection challenges across different industries.
Wireless and Cellular Networking
In the world of wireless communication, this cable is a fundamental component for connectivity:
Antenna Connections: Bridging the gap between a robust outdoor Type-N antenna (such as a high-gain cellular or Wi-Fi antenna) and an indoor SMA-equipped router, modem, or cellular signal booster.
LoRaWAN and IoT Gateways: Connecting large, durable N-type external antennas to compact, low-power SMA-port IoT/LoRa gateways for long-range, low-data communication networks. The flexibility of the RG316 is ideal for routing through walls or within small enclosure boxes.
4G/5G and LTE Systems: Integrating external or auxiliary antennas with communication modules where a change in connector type is necessary, ensuring a reliable signal path for critical high-speed data transfer.
Test and Measurement (T&M) Environments
The RG316's electrical stability and the precision of the connectors are highly valued in laboratory settings:
RF Signal Analysis: Connecting a test instrument with a large Type-N output port (like a Signal Generator or Spectrum Analyzer) to a smaller device or a SMA-terminated probe/fixture under test.
Prototype and R&D Work: Used extensively for temporary connections, rapid prototyping, and bench testing where the cable's flexibility allows for easy repositioning and reconfiguration of test setups without causing connector stress.
Industrial and Embedded Systems
For specialized industrial applications, the cable's durability is a significant advantage:
Telemetry and SCADA Systems: Providing reliable RF links in industrial monitoring and control systems, often running through tight cable trays or industrial enclosures where the RG316's chemical and heat resistance is beneficial.
GPS/GNSS Timing and Positioning: Interconnecting high-precision N-type GPS antennas with SMA-input receivers for navigation and timing applications, where signal integrity is non-negotiable.
Conclusion: Your Reliable RF Interconnect Solution
The N Male to SMA Male RG316 RF Coaxial Cable Assembly is more than just a component; it is a precision tool designed to optimize the performance and flexibility of your high-frequency systems. It expertly addresses the common challenge of mismatched connector interfaces, providing a low-loss, highly durable, and extremely adaptable solution.
By choosing this RG316 assembly, you invest in:
Unmatched Flexibility: Effortless routing in compact spaces.
Consistent Signal Integrity: Reliable performance across wide frequency ranges.
Professional Durability: High-quality construction for long-term use in various environments.
Upgrade your connectivity today and experience the difference that a specialized, high-quality coaxial cable can make in achieving your system's peak performance.
